MAXILYZER ST is a handheld measuring instrument for industrial combustions, emission- and process monitoring. The measured data and calculations are clearly presented. High measuring accuracy, user-friendliness and reliability are some of the outstanding features of this innovative product. Accurate measurements of O2, CO/H2, CO40.000, NO, NO2, SO2, temperatures, pressure (draft) as well as precise calculation of various parameters such as lambda, combustion efficiency (Eta), flue gas loss (qA), dew point, NOx and CO2.
| General data |
|
| Dimensions H x W x D |
350 x 420 x 220 mm |
| Weight |
approx. 7600 g (depending on sensors) |
| Display type |
3.5" TFT |
| Operating temperature |
0 to 40 °C |
| Storage temperature |
-20 to 50 °C |
| Data interface |
QR code generator Bluetooth® |
| Power supply |
AC mains unit 220 to240 V |
| O2 (oxygen) |
|
| Measuring range |
0 to 21.0 vol.-% |
| Accuracy |
±0.2 vol.-% RDG |
| Resolution |
0.1 vol.-% |
| CO (carbon monoxide) with H2-compensation |
|
| Measuring range |
0 to 10,000 ppm |
| Accuracy |
±5 ppm (< 50 ppm) |
| ±5 % RDG (> 50 ppm) |
|
| Resolution |
1 ppm |
| CO2 (carbon dioxide) calculated |
|
| Measuring range |
0 to CO2 max. |
| Accuracy |
±0.2 vol.-% |
| Resolution |
0.1 vol.-% |
| Flue gas temperature |
|
| Measuring range |
0 to 1,150 °C |
| Accuracy |
±1 °C + 1 digit (< 300 °C) |
| ±1 % RDG (> 300 °C) |
|
| Resolution |
0.1 °C |
| Ambient air temperature |
|
| Measuring range |
-20 to 200 °C |
| Accuracy | ±3 °C + 1 digit (-20 < 0 °C) |
| ±1 °C + 1 digit (0 < 200 °C) | |
| Resolution | 0.1 °C |
| Draft/differential pressure |
|
| Measuring range | ±70 hPa (draft) / ±150 hPa (diff. pressure) |
| Accuracy | ±0.02 hPa (< 2.00 hPa) |
| ±1 % RDG (> 2.00 hPa) | |
| Resolution |
0.01 hPa (< 20 hPa) |
| 0.1 hPa (> 20 hPa) | |
| Pitot | |
| Measuring range | 0.5 to 70 m/s |
| Accuracy | ±0.8 m/s |
| Resolution | 0.1 m/s |
| Barometric pressure | |
| Measuring range | 500 to 1,150 hPa |
| Accuracy | ±10 hPa |
| Resolution | 1 hPa |
| Option: COhigh (carbon dioxide) |
|
| Measuring range | 0 to 4.0 vol.-% (= 40,000 ppm) |
| Accuracy |
±10 ppm |
| ±5 % RDG | |
| Resolution | 0.001 vol.-% |
| Option: NO2 (nitrogen dioxide) |
|
| Measuring range |
0 to 500 ppm |
| Accuracy |
±5 ppm (< 100 ppm) |
| ±5 % RDG (> 100 ppm) | |
| Resolution |
0.1 ppm |
| Option: SO2 (sulfur dioxide) |
|
| Measuring range |
0 to 2,000 ppm |
| Accuracy |
±5 ppm (< 200 ppm) |
| ±10 % RDG (> 200 ppm) | |
| Resolution |
0.1 ppm |
| Option: NO (nitrogen oxide) |
|
| Measuring range |
0 to 5,000 ppm |
| Accuracy |
±5 ppm (< 50 ppm) |
| ±5 % RDG (> 50 ppm) | |
| Resolution |
1 ppm |
| Option: NOlow (nitrogen oxide) | |
| Measuring range | 0 to 300 ppm |
| Accuracy | ±2 ppm (< 40 ppm) |
| ±10 % RDG (> 40 ppm) | |
| Resolution | 0.1 ppm |
| Option: CO2 (carbon dioxide) |
|
| Measuring range |
0 to 20 vol.-% |
| Accuracy |
±1 vol.-% |
| Resolution |
0.1 vol.-% |
