Ready-to-use test set for professional tightness tests.
The S4600® ST Set perform accurate measurement of pressure and differential up to 5 bar.
| Scope of delivery | |
| M066030116 | Pressure meter S4650 ST (up to 5 bar) |
| 500670 | Adjusting valve |
| 500690 | Y-connector |
| 500678.2 | 2x Conical test plug ¾" to 1¼" |
| 500679.2 | Stage stop plug ½" and 1" |
| 522952 | Silicon hose |
| 523082 | Pumpball with valve |
| 500685 | Connection hose 1000 mm with nipple DN2.7 and coupling DN5 |
| 500687 | 2x Connection hose 300 mm with nipple DN5 and coupling DN5 |
| 511035 | microSD card 4 GB with card reader |
| 523493 | Power supply unit |
| 523506 | Charging cable |
| 500902 | Case |
| General data | |
| Dimensions H x W x D | 143 x 66 x 37 mm |
| Weight |
approx. 228 g |
| Material housing |
Plastic (PA) |
| Display type |
2.8" TFT (240 x 320 pixels) |
| Operating temperature |
0 to 40 °C |
| Storage temperature |
-20 to 50 °C |
| Data interface |
Bluetooth® QR code generator microSD card Wireless infrared connection with optional EUROprinter |
| Power supply |
Mini USB mains unit (5 V) |
| Battery type |
rechargeable lithium-ion battery 3.6 V / 1,800 mAh |
| Memory type |
optional microSD card up to 16 GB |
| Ingress protection rating |
IP42 (EN 60529) |
| Barometric pressure |
500 to 1150 hPa |
| Technical data pressure I |
|||
| Model |
Measuring range
|
Max. overpressure
|
Response delay (t90)
|
| S4650 ST |
±5 bar |
16 bar |
< 10 seconds |
| Technical data pressure II |
|||
| Model |
Accuracy
|
Resolution
|
Connection type
|
| S4650 ST |
±5 hPa ±0.50 % RDG ±1 digit |
0.1 hPa (< 1,000) 1 hPa (> 1,000) |
2x Ø 8 mm |
